Description
General product description:
Double-guided linear grating (Double Deflection Linear Bar Grille)
The double-direction linear grate is a professional solution for air distribution in air conditioning and ventilation systems. HVAC
It combines high precision in air direction control with an elegant architectural appearance that complements various interior designs. .
The grub relies on bidirectional feathers Double Deflection Blades It allows independent horizontal and vertical control of the airflow path.
This ensures a balanced air distribution and achieves appropriate values for throw and spread. Without causing annoying air currents or a rise in temperature
This type of grate is ideal for side installation of air conditioning and is most often installed in the decorative block or on the walls.
The grille is manufactured from high-quality extruded aluminum, characterized by its strength, durability, and lightweight design, with an electrostatic powder coating finish that gives it a beautiful and attractive appearance. It is available in several colors according to project requirements. .
Key features:
· Modern linear design suitable for all types of interior decorations .
· High quality, made from pure aluminum with powder coating.
· Smooth and quiet air distribution without noise .
· Air can be directed at multiple angles via the Deflection Blade.
· Suitable for installation in gypsum ceilings .
· Available in white and black.
· Lightweight.
· Easy to install, disassemble, clean, and maintain .
· Cleanable and washable.
Technical details:
|
Article |
Details |
|
the name |
Lener Bar Grill |
|
Type |
Bar Grill 1 GRILL DIFFUSER |
|
Shape |
Rectangle as in the picture |
|
Brand |
LP |
|
Material |
100% Aluminum |
|
The structure |
All parts of the grill are made of aluminum. |
|
Aluminum thickness |
5 mm for the frame and the rest of the parts according to the international standard. |
|
height |
All sizes are available upon request. |
|
the color |
white color RAL 9016black color RAL 9005and the option to request a color |
|
Paint type |
High-quality powder coating |
|
Internal blades |
Internally oriented blades are available |
|
Air direction control |
Yes, code routing is possible. |
|
Available types |
SUPPLY & RETURN |
|
Damber |
Available only at the supply store |
|
Country of origin |
United Arab Emirates |
Standardized technical table (only 1 meter long)
Double Deflection Linear Bar Grille
Material: Aluminum | Blades: Double Deflection | Low Noise
📝 Consultant accreditation notes:
· The values above are DESIGN DATA For use in project schedules
· The final values depend on STATIC PRESSURE +PLENUM BOX +VCD
· Datasheets for all sizes and types are available for download.
Product dimensions:
|
Back size |
Front size |
Depth |
Length |
|
100MM |
150MM |
70MM |
optional |
|
120MM |
170MM |
70MM |
optional |
|
150MM |
200MM |
70MM |
optional |
|
200MM |
250MM |
70MM |
optional |
|
250MM |
300MM |
70MM |
optional |
Uses:
· residential villas
· Hospitality and hotel buildings
· Malls and shops
· Theaters and halls
· Offices and administrative headquarters
· projects HIGH-END INTERIOR DESIGN
Other options:
· You can request the addition of the PLENUM BOX
· The addition of VOLUME CONTROL DAMPER can be requested
· Multiple and different sizes can be ordered
· Special rates are available for large projects.
· Special rates are available for businesses and retail stores.
