rectangular linear grilles

General Product Description:

General Definition – Square Ceiling Diffuser (Square Ceiling Diffuser)

The stainless steel square ceiling diffuser is an advanced air distribution solution for air conditioning and ventilation systems (HVAC),

 combining balanced airflow performance with a luxurious architectural appearance, making it an ideal choice for projects that demand a high level

of quality and durability alongside aesthetic appeal.

The diffuser's design is based on multiple stepped cones (Multi-Cone Design) that allow for gradual and balanced air discharge in four directions

, which helps improve air distribution within spaces.

The diffuser is manufactured from high-quality stainless steel, which boasts excellent resistance to rust, moisture, and environmental factors, making it suitable for use in

sensitive environments such as commercial kitchens, laboratories, hospitals, swimming pools, and coastal areas, in addition to high-end residential and commercial projects.

The polished finish of the stainless steel also provides an elegant appearance that blends seamlessly with both modern and classic interior designs.

The diffuser is primarily used for supply air applications (Supply Air), and can be easily installed on gypsum ceilings or false ceilings

, with the possibility of connecting it to a plenum box (Plenum Box) and adding a volume control damper (VCD) to adjust the airflow and achieve precise system balancing

according to project requirements.

Key Features:

·      Design: Four-way air distribution  .

·      Finish: Polished stainless steel

·      Color: Natural stainless steel

·      Uniform four-way air distribution without noise.

·      Stable operating performance with low noise level

·      Suitable for installation in gypsum and false ceilings.

·      Available in gold and silver colors.

·      Easy to install, dismantle, clean, and maintain.

·      Washable.

Technical Details:





Technical Table:

4 WAY SQUARE DIFFUSER
Material: Aluminum Layers | Low Noise



📝 Consultant Approval Notes:

·      The above DESIGN DATA  values are for use in project tables.

·      The final values depend on  STATIC PRESSURE +PLENUM BOX +VCD

·      Datasheets are available for all sizes and types and can be downloaded.

Product Sizes:



Uses:

·      Hospitals

·      Restaurants

·      Hospitality buildings and hotels

·      Malls and retail stores

·      Cafes

·      Retail stores



Other options:

·       A PLENUM BOX  can be ordered

·      A VOLUME CONTROL DAMPER can be ordered

·      Multiple and different sizes are available

·      Special prices are available for large projects

·      Special prices are available for commercial companies and retail stores
